Operating Instructions Safety Switch CES-I-AR-U-C04
31
Ordering information and accessories
Designation Version Order no.
CES-I-AR-U-C04-U05-119470 Safety switch, unicode, connection cable PUR 5 m, flying lead 8 x 0.14 mm² 119470
CES-I-AR-U-C04-U10-119471 Safety switch, unicode, connection cable PUR 10 m, flying lead 8 x 0.14 mm² 119471
CES-I-AR-U-C04-U20-119472 Safety switch, unicode, connection cable PUR 20 m, flying lead 8 x 0.14 mm² 119472
CES-I-AR-U-C04-USA-119473 Safety switch, unicode, connection cable PUR 1,000 mm with M12 plug connector, 8-pin 119473
CES-I-AR-U-C04-SG-119469 Safety switch, unicode, M8 plug connector, 8-pin 119469
Bridging plug M12, 4-pin, plug 097645
Y-distributor M12, 1x8-pin, 2x5-pin 097627
Y-distributor with connecting
cable
M12, 1x8-pin, 2x5-pin 111696
Connection cable with plug
connector M12 8-pin, PVC, flying
lead, conductor cross-section
0.25 mm²
M12, 8-core, 5 m 100177
M12, 8-core, 10 m 100178
M12, 8-core, 20 m 100179
Connection cable with plug
connector M8 8-pin, PUR, flying
lead, conductor cross-section
0.14 mm²
M8, 8-pin, 5 m 106671
M8, 8-pin, 10 m 106672
M8, 8-pin, 20 m 106673
Connection cable with plug
connector M8 8-pin, PVC, flying
lead, conductor cross-section
0.14 mm²
M8, 8-pin, 5 m 110933
M8, 8-pin, 10 m 110934
M8, 8-pin, 15 m 110935
M8, 8-pin, 20 m 111603
CES-A-BBN-C04-115271 Actuator 42 x 25 x 18 mm 115271
CES-A-BDN-06-104730 Actuator 26 mm x ∅ 6 mm 104730
Tip!
You will find further connection material, in particular for series connection, in the
current Non-Contact Safety System CES catalog at www.euchner.de.
Inspection and service
Warning!
Loss of the safety function because of damage to the system.
In case of damage, the related component must be replaced completely.
Only accessories or spare parts that can be ordered from EUCHNER may be
replaced.
Regular inspection of the following is necessary to ensure trouble-free long-term
operation:
Ì Check the switching function (see section Functional check)
Ì Check the secure fastening of the devices and the connections
Ì Check for soiling
No servicing is required. Repairs to the device are only allowed to be made by
the manufacturer.
Note!
The year of manufacture can be seen in the lower right corner of the rating plate.
The current version number in the format (V X.X.X) can also be found on the device.
The safety door must be re-adjusted when the device indicates that the actuator
is in the limit range.
