Operating Instructions Safety Switch TK...
Subject to technical modifications; no r
esponsibility is accepted for the accuracy of this information. © EUCHNER GmbH + Co. KG
094207-05-06/13 (translation of the original operating instructions)
Version TK.. (Cable entry M20x1.5)
Break out the required entry opening.
Fit the cable gland with the appropriate degree of
protection.
For terminal assignment see Figure 2.
Tighten the screws with a torque of 0.5 Nm.
Check that the cable entry is sealed.
Close the cover and screw in position.
Version TK..SR.. (plug connector)
For terminal assignment see Figure 2.
Functional check
Warning! Danger of fatal injury as a result of faults
in installation and functional check.
Before carrying out the functional check, make
sure that there are no persons in the danger
area. Observe the valid accident prevention
regulations.
After installation and any fault, the safety function must
be fully checked. Proceed as follows:
Mechanical function test
The guard locking pin must move easily to the locked
position. For checking, close the safety guard several
times and extend and retract guard locking pin.
Electrical function test
1. Switch on operating voltage.
2. Close all safety guards.
Guard locking by solenoid force: Activate
guard locking.
The machine must not start automatically.
It must not be possible to open the safety guard.
3. Enable operation in the control system.
It must not be possible to deactivate the guard
locking as long as operation is enabled.
4. Disable operation in the control system and
deactivate guard locking.
The safety guard must remain locked until there is
no longer any risk of injury.
It must not be possible to start the machine as long
as the guard locking is deactivated.
Repeat steps 2 - 4 for each safety guard.
Service and inspection
If damage or wear is found, the complete switch
must be replaced.
Replacement of individual parts or assemblies
is not permitted!
Do not grease guard locking pin.
No servicing is required, but regular inspection of
the following is necessary to ensure trouble-free long-
term operation:
correct switching function
secure mounting of components
dirt and wear
sealing of cable entry
loose cable connections or plug connectors.
Note:The year of manufacture can be seen in the
bottom, right corner of the rating plate.
Exclusion of liability under the following
circumstances
incorrect use
non-observance of the safety instructions
non-compliance with safety regulations
failure to perform functional checks.
EC declaration of conformity
The manufacturer named below herewith declares that
the product fulfills the provisions of the directive(s)
listed below and that the related standards have been
applied.
EUCHNER GmbH + Co. KG
Kohlhammerstraße 16
70771 Leinfelden-Echterdingen, Germany
Directives applied:
Machinery directive 2006/42/EC
Standards applied:
EN 60947-5-1:2004 + Cor.:2005 + A1:2009
EN 1088:1995+A2:2008
Leinfelden, July 2010
Dipl.-Ing. Michael Euchner
Director
Duc Binh Nguyen
Authorized representative empowered to draw up
documentation
The signed EC declaration of conformity is included
with the product.
Technical data
Parameters Value
Housing material Reinforced thermoplastic
Degree of protection according to IEC 60529
Cable entry
IP67
Plug connector IP65
Mechanical life 1x10 6 operating cycles
Ambient temperature -20...+55 °C
Weight Approx. 0.6 kg
Degree of contamination
(external, acc. to EN 60947-1)
3 (industrial)
Installation position Any
Locking force
5000 N
(in case of head mounting)
Actuation frequency
3500 / h
Switching principle Slow-action switching contact
Contact material Silver alloy, gold flashed
Connection type
TK...
Screw terminal with cable entry
TK...SR6 Plug connector SR6, 6-pin+PE
TK...SR11 Plug connector SR11, 11-pin+PE
Conductor cross-section 0.34 ... 1.5 mm²
Rated insulation voltage
TK... , TK...SR6
U
i
= 250 V
TK...SR11 U
i
= 50 V
Rated short-circuit current 100 A
Rated impulse withstand voltage
TKP... , TK...SR6
U
imp
= 2.5 kV
TK...SR11 U
imp
= 1.5 kV
Switching voltage, min.
12 V
at 10 mA
Utilization category to EN 60947-5-1
TK... , TK...SR6
AC-15 4 A 230 V / DC-13 4 A 24 V
TK...SR11 AC-15 4 A 50 V / DC-13 4 A 24 V
Switching current, min., at 24 V 1 mA
Short circuit protection
(control circuit fuse)
4 A gG
acc. to IEC 60269-1
Conv. thermal current I
th 4 A
Solenoid operating voltage
TK...024
AC/DC 24 V (+10%/-15%)
TK...048 AC/DC 48 V (+10%/-15%)
TK...110 AC 110 V (+10%/-15%)
TK...230 AC 230 V (+10%/-15%)
Duty cycle 100 %
Power consumption 8 W
Reliability figures according to EN ISO 13849-1
B
10d 2 x 10 6
