1

Unpack and Organize

3

S e c t i o n 1

Unpack and Organize

The table below lists the parts and components needed to retrofit a Sensor+ touring rack

(SP+ 48, 96, or 96 “Double Small”) to become a Sensor3 rack with a CEM3. Each part is

listed to reflect the different quantities for the different kits and types of racks.

* Need/quantity based on specific rack or door type. See Sensor3 Touring Rack Retrofit Kit order sheet for details or

contact ETC Technical Services (see

Contacting Technical Services, page 1

).

Parts/Components

ETC Part Number

SP+48/96

Universal Kit

7143K1005

Part

s Includ

ed in the Kit

Touring Backplane Baffle

7053A3023

1

CEM3 SP DMX/Beacon Control Assembly

7142B5610

1

Sensor3 Touring Rack Door Label

7143A4119

1

CEM+ to CEM3 Backplane Power Adapter Harness

7141B7007

1

Sensor3 Rack Backplane Assembly

7142A2006-CFG

1

Sensor Touring Rack CEM+ to CEM3 Retrofit Manual

7143M2300

1

Second Fan Indicator Label

7143A4001

1

Screw 8-32 X 3/8 Ph PH MS CP W/Patch

HW377

5

Cable tie 4" Hi-temp Black

HW7121

5

Screw M3.5 x 4 mm

HWM1036

2

CEM3 Backplane 1/8” #8 screw spacer

HW9343

5

Additional Items

SP48

SP96

SP96

“Double Small”

Ad

dition

al

Lin

e Items

SP48/96 Door Baffle Replacement Kit

7143A2002

1*

2*

1*

SP96 “Double Small” Right Baffle Replacement Kit

7143A2005

0

0

1*

SP48/96 Left Door Replacement Kit

7143B3004

1*

2*

1*

SP96 Right Door Replacement Kit

7143B3007

0

0

1*

Sensor3 AF Card (Optional)

7150B5623

2

4

4

CEM3

7140A1000

1

1

1

Required Tools

#1 Phillips screwdriver

#2 Phillips screwdriver

Flat-blade or square-drive screwdriver

5/16” nut driver or socket

Diagonal wire cutter

Permanent marker

Wire strippers
