6 • CE Source FourPAR
English
Wiring information
A plug of at least 2.5 amp (220/240V) rating should be attached to
the luminaire's mains lead. The wires in the mains lead are
1.5mm 2 each and coloured in accordance with the following code:
Accessories
HPL lamps
HPL lamps are tungsten halogen lamps.
Important: Verify that the HPL lamp you use is suitable for the
voltage at your facility. 115V, 120V, 230V, and 240V HPL lamps
are available. Operating lamps above their rated voltage
reduces lamp life and can cause premature lamp failure.
Green and Yellow: Earth
Blue: Neutral
Brown: Live
WARNING! This luminaire must be earthed.
Current rating:
120V/5 amp maximum
240V/2.5 amp maximum
Operating frequency: 50/60Hz
Colour frame (190mm sq/170mm inside diameter) 407CF
Safety cable (80cm) 400SC
C-clamp 400CC
Very Narrow Spot lens 400-VNSP
Narrow Spot lens 400-NSP
Medium Flood lens 400-MFL
Wide Flood lens 400-WFL
Set of four CE Source FourPAR lenses
(VNSP, NSP, MFL, WFL)
400LS4
Set of five CE Source FourPAR lenses
Clear Flat, VNSP, NSP, MFL, WFL)
400LS5
WARNING! Do not use lamps other than HPL in CE Source
FourPAR luminaires. Use of lamps other than HPL will void
CE safety conformity and warranty.
t 180 ° c
