1.3.3 Remove the cap from the carboy.
1.3.4 Place the fitting into the cap. The threaded portion of the barb fitting should be on the
inside of the cap.
1.3.5 Place the washer and then the nut onto the barb fitting and tighten.
1.3.6 Place the cap back on the carboy.
1.3.7 The barb fitting for the drain line is located on the right side towards the back of the unit.
Place the supplied ½" tubing onto the barb fitting and the other end on the barb fitting on the
carboy.
NOTE: Ensure the tubing goes in a DOWNWARD direction the entire length to avoid
back-ups.
1.3.8 In the fluidics compartment there is a safety drain in the case of a catastrophic failure
to one of the pumps or 5-way valve assemblies. This drain is located under the unit and will
evacuate any pooled reagent from the interior cabinet of the AutoBlock. A tray or tubing
and container should be placed at the outlet point to contain any potential liquid coming
from this drain port.
