A.4.1 Power Supply

Feature Details

Auxiliary power supply

DC source only

Auxiliary supply input voltage

24 V +20%

Auxiliary supply input power

30 W

A.5 Maestro Connectors

A.5.1 Encoder Input

Feature Details

Interface

Incremental Quadrature Encoder

Output current capability

200 mA

Maximum frequency

20 MHz

Edge separation between A & B

Index (marker):

Is available

Maestro Installation Guide

Technical Specifications

MAN-MASIG (Ver 1.33)

A-4
