Tuba Installation Guide Installation
MAN-TUBIG (Ver. 1.502)
www.elmomc.com
52
Pin Signal Function Pin Positions
11 IN3 Programmable input 3
1 2 IN2 Programmable input 2
1 3 IN1 Programmable input 1
1 4 INRET10 Programmable inputs return 10
1 5 INRET9 Programmable inputs return 9
1 6 INRET8 Programmable inputs return 8
1 7 INRET7 Programmable inputs return 7
1 8 N.C. Not Connected
1 9 INRET6 Programmable inputs return 6
20 N.C. Not Connected
21 INRET5 Programmable inputs return 5
22 INRET4 Programmable inputs return 4
23 INRET3 Programmable inputs return 3
24 INRET2 Programmable inputs return2
25 INRET1 Programmable inputs return 1
Table 12: Digital Inputs (on the Committed I/O port) Pin Assignments
