Guitar Installation Guide Technical Specifications
MAN-GUIIG (Ver. 1.601)
www.elmomc.com
64
4.4. Power Ratings for 200 V Models
Feature
Un
it
s
3/
20
0
6/
20
0
10/
200
17/
200
20/
200
R30/
200
Minimum supply voltage VDC 46
Nominal supply voltage VDC 170
Maximum supply voltage VDC 195
Maximum auxiliary supply
voltage
VDC 195
Maximum continuous power
output
W 480 960 1600 2700 3200 4800
Efficiency at rated power (at
nominal conditions)
% > 97
Maximum output voltage 97% of DC bus voltage at f=22 kHz
Amplitude sinusoidal/DC
continuous current
A 3 6 10 17 20 30
Sinusoidal continuous RMS
current limit (Ic)
A 2.12 4.2 7 12 14.1 21.2
Peak current limit A 2 x Ic No peak
Weight g (oz) 165 g (5.8 oz)
Dimensions mm
(in)
80 x 61 x 24.5 (3.15" x 2.4" x 0.965")
Digital in/Digital out/ Analog in 6/4/1
Mounting method PCB mount
The following notes apply to all the above Power Rating models up to 100 V and 200 V.
Note on current ratings: The current ratings of the Guitar are given in units of DC amperes
(ratings that are used for trapezoidal commutation or DC motors). The RMS (sinusoidal
commutation) value is the DC value divided by 1.41.
4.5. Auxiliary Supply
Feature Details
Auxiliary power supply Isolated DC source only
Auxiliary supply input voltage 12 VDC up to the specified voltage rate for each
servo drive, refer to the ‘Maximum auxiliary
supply voltage’ rate in the ‘Power Ratings’ table
(Section 4.3).
Auxiliary supply input power 7 VA
