Chapter 6: Pow ering Up
After the Gold Panther is connected to its peripheral devices, it is ready to be powered up.
Caution: Before applying power, ensure that
1.
The DC supply is within the specified range.
2. The proper plus-minus connections are in order.
3. The VN- is not connected to the PE nor to the Neutral, when working with a
non-isolated power supply.
6.1. Initializing the System
After the Gold Panther has been connected and mounted, the system must be set up and initialized.
This is accomplished using the Elmo Application Studio, Elmo’s Windows-based software
application. Install the application and then perform setup and initialization according to the
directions in the Elmo Application Studio II User’s Manual.
