Gold Panther Installation Guide
MAN-G-PANIG-EC (Ver. 1.000)
|Connectors| www.elmomc.com
13
Table of Contents
4.2.2.4. Connector J2
Feedback, Analog input,
communications– see Section 7.5 in
the manual: MAN-G-Drive
Hardware.
Connector Type: 1.27 mm pitch
0.41 mm sq
For full details about connecting
feedback port A see Section 7.6.1 in
the MAN-G-Drive Hardware manual
for full details.
For full details about connecting
feedback port B see Section 7.6.2 in
the MAN-G-Drive Hardware manual
for full details.
For full details about connecting
feedback port C see Section 7.6.3 in
the MAN-G-Drive Hardware
manual.
Analog Inputs – see Section 7.7.3 in
the manual: MAN-G-Drive
Hardware.
For full details about connecting
communication see Section 7.8 in
the manual: MAN-G-Drive
Hardware.
Note regarding the EtherCAT and CAN communication options:
The J2 Connector exports all supported communication links. However, note that CAN and
EtherCAT are not available in the same version of the Gold Panther and are thus not operational
simultaneously. See the part number diagram in Section 4.1 above for the different Gold Panther
configurations.
