Gold Hawk Installation Guide
Installation
MAN-G-HAKIG (Ver. 1.001)
59
4.11. Communications
The communication interface may differ according to the user’s hardware. The Gold Hawk can
communicate using the following options:
Standard
EtherCAT
G-GUT
XXX
/
YYY
S
X
G-GUT
XXX
/
YYY
E
X
CAN
EtherCAT
USB 2.0
USB 2.0
Ethernet
RS-232 (TTL Logic Level)
RS-232 (TTL Logic Level)
Table 18: Gold Hawk Communication Options
For ease of setup and diagnostics of CAN communication, RS-232 and CAN may be used
simultaneously.
When the EtherCAT is connected, and FoE in operation, the USB cable connection
must be disconnected.
4.11.1. RS-232 Communication (J2)
The Gold Hawk provides RS-232 with TTL voltage level (Refer to the voltage level in the
technical specification in section 5.6 Communications). Therefore, to implement standard
RS-232, you must add a RS-232 Line Driver/Receiver on the integration board in order to
translate the TTL logic level to the standard RS-232 voltage level.
The following table describes the Gold Hawk RS-232 pinout:
Pin (J2) Signal
Function
45
RS232_Rx
RS-232 receive (TTL logic level)
48
RS232_Tx
RS-232 transmit (TTL logic level)
46
RS232_COMRET
Communication return
Table 19: RS-232 Pin Assignments
