Chapter 3: Technical Information
3.1. Technical Data
Feature Units
20/10
0
35/10
0
50/10
0
10/20
0
17/20
0
20
/20
0
Minimum supply voltage VDC 14 23
Nominal supply voltage VDC 85 170
Maximum supply voltage VDC 95 195
Maximum continuous power output W 1600 2800 4000 1650 2800 3240
Efficiency at rated power (at nominal
conditions)
% > 98
Maximum output voltage VDC 14 V to 96 V 23 V to 195 V
Continuous current limit (Ic)
amplitude of sinusoidal current, or DC
trapezoidal commutation
A 20 35 50 10 17 20
Sinusoidal continuous RMS current
limit (Ic)
A 14.2 24.7 35.4 7.07 12 14.3
Peak current limit A 2 x Ic
Weight g (oz) 212 g (7.47 oz)
Dimensions mm (in) 80 x 61 x 31 mm (3.15" x 2.4" x 1.2")
Digital in/
Digital out/
Analog in
6/4/1
Mounting method PCB mount
Table 1: Power Ratings
Note on current ratings: The current ratings of the Gold Hawk are given in units of DC
amperes (ratings that are used for trapezoidal commutation or DC motors). The RMS
(sinusoidal commutation) value is the DC value divided by 1.41.
