DIGIWEIGH DWP-800 DWP-102E Indicator User Manual
Page 7
- 6 -
SLP no: Set to “SLP no” means the indicator will never sleep.
SLP 3: Set the time span 3 minutes for the sleep. This sleep mode has two options:
“off & dot”, which can be selected by pressing FUN Key
when displaying
“SLP 3” . ”off” means cutting off the power and “dot” means only a dot at the last digit will be displayed. When “dot”, weight
changing can wake up the indicator.
SLP 5/10/15: Same as SLP 3.
“F2 BK”: Backlight mode setting For LCD version
Auto mode: The backlight will distinguish when no action is taken during a certain time.
Off mode: The backlight is off all the time.
On mode: The backlight is always on.
“F3 KEY”: MOD Key setting
KEY 1
To set the MOD Key for counting, gross / net weight display switch.
KEY 2
To set the MOD Key for accumulation & print.
KEY 3
To set the MOD Key for holding the weight value.
KEY 4
To set the MOD Key for setting tare value in advance.
KEY 5
To set the MOD Key for animal weighing parameters setting.
“F4 CHK”: Check-weighing setting
Options: BEEP 1/2/3.
“F5 Brt”: Adjust the brightness of LED display. For LED version
Select 1-8 : 8 is most bright
“F5 INP”: Display the internal counts For LCD version .
Used to check the connection of loadcell and working status of ADC circuit.
Press “TARE” to exit.
“F6 INP”: Display the internal counts For LED version
“F6 CAL”: Calibration for LCD Version. See below:
“F7 CAL”: Calibration
“PN”: Press FUN Key to enter “PN”. Initiate password is 0000
“P1 SP”:
Set AD converting speed. Options: 1/2/3/4/5. 1 is the fastest and 5 is the slowest.
“P2 AUT”: Select the “Power on “ zero maintenance, Options: 0/2/5/10/20/50/100% of the capacity.
“P3 RAN”: Select the manually zero maintenance, Options: 2/ 4/10/20/50/100% of the capacity.
“P4 AZ”: Select the auto zero maintenance, Options: 0.5d/1d/2d/4d. “d” means division.
“P5 DEC”: Set the decimal point. Options: 0/0.0/0.00/0.000/0.0000.
“P6 CAP”: Set the capacity.
“P7 INC”: Set division increment. Options: 1/2/5/10/20/50.
“P8 CAL”: Calibration
After finishing all necessary settings above, the indicator is ready for calibration. (Note: If the scale has settings already done you can directly
calibrate it.) Press FUN Key when displaying
“P8 CAL”. Display will show “noLoAd”. Empty the platform by removing the weight if any. When
platform is empty and STABLE indicator is on then press FUN Key to confirm. Display shows
“XXXXXX”. Set it to be the weight of the weigher
you want to put on. Press FUN Key to confirm, and it
will show “LoAd”. Put the calibration weigher on the platform and press FUN Key after the
STABLE indicator is on. Indicator will go to weighing state. The calibration is finished.
“P9 INT”: Initialize the memory to ex-work state.
“P10 RS”: Communication mode.
This option is used for the RS232C serial port m
ode setup. Options: “RS Cot” is continuous Data Transmission for using Remote
Display o
r External Display, “RS Prt” is used for the Serial Printer. “RS Aut” is used for “transmission after every weighing”.
“P11 FL”: Weight adjustment for acceleration of gravity.
“P12 KB”: When “on”, keyboard is pressed with sound.
“P13 UT”: Unit setting. Lb, U1 or U2 is optional, which could be “ON” or “OFF” through pressing the FUN Key and TARE Key. When U1/U2 is
“ON”, the conversion coefficient can be set through pressing UNIT Key while self-checking. When U1/U2 is “OFF”, it could not be set unless
entering the P13 UT menu and set it
“ON”.
“P14 Pn”: Press “FUN” to display “P1 ----” set the passwords and press “FUN”. It display “P2 ----” and set passwords again to confirm. When
successful ,it will show
“Done”
