Section 3 - Controls and Indicators
3-24 31200537
Accessory Control Lever
Turn Signals and Low/High Beam Headlights
• Push accessory control lever (1) forward (2) to activate left turn signal.
• Pull lever backward (3) to activate right turn signal.
• The lever must be manually returned to the center position to deactivate either
turn signal. The lever will not cancel automatically after a turn.
• Pull lever up (4) to switch between low and high beam headlights.
Front Windshield Wiper and Horn
• Rotate hand grip (5) to activate front windshield wiper, O - Off, J - Continuous or
I - Fast
• Depress end of lever (6) to activate windshield wiper fluid.
• Depress button (7) to sound horn.
OZ3450
1
2
3
4
OZ3460
1
5
6
I
O
J
7
