Page 108

Section 5 - Attachments and Hitches
5-30
31200537
Grapple Bucket
Use Appropriate Bucket Capacity Chart
To determine maximum capacity, refer to “Telehandler/
Attachment/Fork Capacity” on page 5-4.
The joystick (1) controls movement of the boom.
The attachment tilt roller switch (2) controls bucket tilt.
• Push roller switch down to tilt up.
• Push roller switch up to tilt down.
OZ1450
OZ2210
2
1
OZ2530
3
4
5
