Section 5 - Attachments and Hitches
5-28 31200537
Multi-Purpose Bucket
Use Appropriate Bucket Capacity Chart
To determine maximum capacity, refer to “Telehandler/
Attachment/Fork Capacity” on page 5-4.
The joystick (1) controls movement of the boom.
The attachment tilt roller switch (2) controls bucket tilt.
• Push roller switch down to tilt up.
• Push roller switch up to tilt down.
OZ2540
OZ2210
2
1
OZ2550
3
4
5
