CONFIGURATION MENU
1) Edit Cons
oi Fails
This option allows the operator to select the number of consecutive oi failures before an
oi fault will be generated. Selectable range is
1
to
1000
.
2) Edit Temp Setpoint
This option allows the operator to select the temperature at which the optics heater begins
operating.
3) Edit Heater Setpoint
This option allows the operator to select the maximum amount of heater power allowed, in
percent of full power. (
0%
= heater shut off.)
CALIBRATION MENU
1) Loop Test
This test allows the operator to manually set the analog signal output (
4
to
20
mA) to a
fixed user defined value.
2) D/A Trim
This function allows adjustment of the
4
to
20
mA span factor.
3) Calibrate
oi
This procedure calibrates the oi test signal for all three IR sensors.
1. Bypass/disable all Alarm outputs connected to the detector.
2. Thoroughly clean the sensor and oi reflector for each of the three sensors.
Check each of the three oi source openings for contaminants and clean as
needed.
3. Cover the detector with the provided cover.
4. Initiate oi Calibration. The detector performs the calibration automatically and
notifies the operator upon completion. The procedure takes approximately two
minutes.
5. Upon completion of oi calibration, remove the cover and return all alarm outputs
to service.
Configuration Menu
1) Edit Cons Oi Fails
2) Edit Temp Setpoint
3) Edit Heater Setpoint
Device Setup Menu
1) Configuration Menu
2) Calibration Menu
3) Write Protect
4) HART Setup
5) Set Real Time Clock
