Det-Tronics X3301 Multispectrum IR Flame Detector with HART - Manual (Page 12)

95-8577 10 3.1
STATUS INFO MENU
This menu (read only) shows extensive status information about the detector.
1) Warmup (Y/N) Device is in the power-up time delay (warm-up) mode.
2) Fire (Y/N) Indicates “Y” if the device is in a fire alarm status — analog output is at 20 mA, fire alarm
relay is actuated and LED is red.
3) Auto oi Fault (Y/N) Automatic oi Fault. Check viewing windows and oi reflector plate for cleanliness.
4) Dim Detect Fault (Y/N) Diminished Detection Fault. Excessive background IR radiation. Eliminate IR interference
and/or re-aim/orient detector.
5) Detect Disable Flt (Y/N) Flame detector function has been disabled. Check viewing windows for cleanliness and/
or presence of excessive background IR signal.
6) Snsr Hdwr Fault (Y/N) Sensor hardware fault.
7) HIB Hdwr Fault (Y/N) HART Interface Board hardware fault.
8) Int Comm Fault Internal communication fault.
9) Incompatible Flt Sensor module firmware version is not compatible with HART Interface Board.
10) Voltage Fault (Y/N) Detector operating voltage is out of tolerance.
11) Hardware Menu Refer to sub-menu.
12) oi Menu Refer to sub-menu.
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X3301 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
Status Info Menu
1) Warmup (Y/N)
2) Fire (Y/N)
3) Auto Oi Fault (Y/N)
4) Dim Detect Fault (Y/N)
5) Detect Disable Flt (Y/N)
6) Snsr Hdwr Fault (Y/N)
7) HIB Hdwr Fault (Y/N)
8) Int Comm Fault
9) Incompatible Flt
10) Voltage Fault (Y/N)
11) Hardware Menu
12) Oi Menu
