DETECTOR SETTINGS
This menu shows factory settings relating to relay operation, detector sensitivity and response.
1) Fire Relay (L/NL)
Fire relay contacts, latching (L) or non-latching (NL).
2) Fire Relay (NDE/NE)
Fire relay coil, normally de-energized (NDE) or normally energized (NE).
3) Fault Relay (L/NL)
Fault relay contacts, latching (L) or non-latching (NL).
4) Fault Relay (NDE/NE)
Fault relay coil, normally de-energized (NDE) or normally energized (NE).
5) Aux Relay (L/NL)
Auxiliary relay contacts, latching (L) or non-latching (NL).
6) Aux Relay (NDE/NE)
Auxiliary relay coil, normally de-energized (NDE) or normally energized (NE).
7) Sensitivity (VH/H/M/L)
Detector sensitivity setting: Very high, High, Medium, or Low.
8) Response (
.5/3/6/9
)
Fire alarm processing time in seconds.
HISTORY MENU
This menu provides historical information about the detector. Up to
32
events in each of the three categories will be
kept in non-volatile memory. When the log is full, the oldest event will be overwritten. The most recent event will be
displayed first.
1) Alarm Log
Scroll through
32
Alarm Logs with time, date and temperature stamp.
2) Fault Log
Scroll through
32
Fault Logs with time, date and temperature stamp.
3) General Log
Scroll through
32
General Logs with time, date and temperature stamp.
History Menu
