FM Approval and performance Report – Continued
FIELD OF VIEW
High sensitivity uV & IR, Hi Arc, TDsA On, Quick Fire Off
Fuel size
Distance
feet (m)
Horizontal
(degrees)
Typical Horz. Response
Time (seconds)*
Vertical
(degrees)
Typical Vert. Response
Time (seconds)*
n-Heptane 1 x 1 foot
25
(7.6)
+45
–45
5
8
+45
–30
4
8
Methane 32 inch plume
17.5
(5.3)
+45
–45
3
4
+45
–30
4
4
High sensitivity uV & IR, Very Hi Arc, TDsA On, Quick Fire On
Fuel size
Distance
feet (m)
Horizontal
(degrees)
Typical Horz. Response
Time (seconds)*
Vertical
(degrees)
Typical Vert. Response
Time (seconds)*
n-Heptane 1 x 1 foot
25
(7.6)
+45
–45
12
9
+45
–30
13
6
High sensitivity uV, Low sensitivity IR, Hi Arc, TDsA On, Quick Fire Off
Fuel size
Distance
feet (m)
Horizontal
(degrees)
Typical Horz. Response
Time (seconds)*
Vertical
(degrees)
Typical Vert. Response
Time (seconds)*
n-Heptane 1 x 1 foot
7.5
(2.2)
+45
–45
6
6
+45
–30
9
6
High sensitivity uV, Very High sensitivity IR, Arc Off, TDsA On, Quick Fire On
Fuel size
Distance
feet (m)
Horizontal
(degrees)
Typical Horz. Response
Time (seconds)*
Vertical
(degrees)
Typical Vert. Response
Time (seconds)*
Methane 32 inch plume
7.5
(2.2)
+45
–45
0.9
0.2
+45
–30
0.1
0.1
Very High sensitivity uV & IR, Low Arc, TDsA On, Quick Fire On
Fuel size
Distance
feet (m)
Horizontal
(degrees)
Typical Horz. Response
Time (seconds)*
Vertical
(degrees)
Typical Vert. Response
Time (seconds)*
n-Heptane 1 x 1 foot
42.5
(13)
+45
–45
12
14
+45
–30
11
13
Methane 32 inch plume
32.5
(9.9)
+45
–45
5
7
+45
–30
6
6
High sensitivity uV, Very High sensitivity IR, Hi Arc, TDsA On, Quick Fire Off
Fuel size
Distance
feet (m)
Horizontal
(degrees)
Typical Horz. Response
Time (seconds)*
Vertical
(degrees)
Typical Vert. Response
Time (seconds)*
n-Heptane 1 x 1 foot
30
(9.1)
+45
–45
8
8
+45
–30
10
7
Methane 32 inch plume
32.5
(9.9)
+45
–45
4
5
+45
–30
5
5
Medium sensitivity uV, High sensitivity IR, Hi Arc, TDsA On, Quick Fire On
Fuel size
Distance
feet (m)
Horizontal
(degrees)
Typical Horz. Response
Time (seconds)*
Vertical
(degrees)
Typical Vert. Response
Time (seconds)*
n-Heptane 1 x 1 foot
25
(7.6)
+45
–45
15
7
+45
–30
7
9
Methane 32 inch plume
30
(9.1)
+45
–45
8
6
+45
–30
8
12
*Add 2 seconds for EQP model.
*Add 2 seconds for EQP model.
*Add 2 seconds for EQP model.
*Add 2 seconds for EQP model.
*Add 2 seconds for EQP model.
*Add 2 seconds for EQP model.
*Add 2 seconds for EQP model.
