Det-Tronics X5200 UVIR Flame Detector - Manual (Page 25)

23 95-8546 13.1
FM Approval and performance Report – Continued
Very High sensitivity uV & IR, Low Arc, TDsA On, Quick Fire On
Fuel size Distance feet (m) Typical Response Time (seconds)*
n-Heptane 1 x 1 foot 85 (25.9) 14
Methane 32 inch plume 65 (19.8) 5
*Add 2 seconds for EQP model.
High sensitivity uV, Very High sensitivity IR, Hi Arc, TDsA On, Quick Fire Off
Fuel size Distance feet (m) Typical Response Time (seconds)*
n-Heptane 1 x 1 foot 60 (18.3) 6
Methane 32 inch plume 65 (19.8) 9
*Add 2 seconds for EQP model.
Medium sensitivity uV, High sensitivity IR, Hi Arc, TDsA On, Quick Fire On
Fuel size Distance feet (m) Typical Response Time (seconds)*
n-Heptane 1 x 1 foot 50 (15.2) 5
Methane 32 inch plume 60 (18.3) 5
*Add 2 seconds for EQP model.
High sensitivity uV & IR, Very Hi Arc, TDsA On, Quick Fire On
Fuel size Distance feet (m) Typical Response Time (seconds)*
n-Heptane 1 x 1 foot 50 (15.2) 8
*Add 2 seconds for EQP model.
High sensitivity uV, Low sens. IR, Hi Arc, TDsA On, Quick Fire Off
Fuel size Distance feet (m) Typical Response Time (seconds)*
n-Heptane 1 x 1 foot 15 (4.6) 9
*Add 2 seconds for EQP model.
High sensitivity uV, Very High sens. IR, Arc Off, TDsA On, Quick Fire On
Fuel size Distance feet (m) Typical Response Time (seconds)*
Methane 32 inch plume 15 (4.6) 0.12
*Add 2 seconds for EQP model.
High sensitivity uV, Very High sens. IR, Hi Arc, TDsA On, Quick Fire On
Fuel size Distance feet (m) Typical Response Time (seconds)*
Methane 32 inch plume 15 (4.6) 0.3
*Add 2 seconds for EQP model.
REspONsE CHARACTERIsTICs
High sensitivity uV & IR, Hi Arc, TDsA On, Quick Fire Off
Fuel size Distance feet (m) Typical Response Time (seconds)*
n-Heptane 1 x 1 foot 50 (15.2) 7
Methane 32 inch plume 35 (10.7) 3.5
*Add 2 seconds for EQP model.
High sensitivity uV & IR, Very Hi Arc, TDsA On, Quick Fire Off
Fuel size Distance feet (m) Typical Response Time (seconds)*
n-Heptane 1 x 1 foot 50 (15.2) 8
*Add 2 seconds for EQP model.
