Appendix e, En54 approvals – Det-Tronics X9800 IR Flame Detector User Manual
Page 29

27
95-8554
11.1
appenDiX e
EN54 AppROVALs
INsTRuCTIONs FOR THE AppLICATION OF THE AppROVAL COMpONENT/sysTEM
The installation shall take into account, that the orientation arrow on the flame detector is directed upwards, as the view
angle in this direction is <90°.
The IR-flame detector corresponds to class 1.
AgENCy
Conventional Output
LON Output
certificate/approval
number
basis of approval
certificate/approval
number
basis of approval
VdS –
Construction Product Directive
0786 – CPD – 20779
EN 54-10 + A1
—
—
VdS
G 203084
VdS 2344
VdS 2504
EN 54-10 + A1
—
—
S 212002*
VdS 2344
EN 54-13
S 212002*
VdS 2344
EN 54-13
BRE –
EC – Certificate of Conformity
—
—
0832 – CPD – 1377
EN 54-10 + A1
EN 54-17
LPCB
973e/01
EN 54-10 + A1
973a/01
EN 54-10 + A1
EN 54-17
* approved for use in conjunction with the en54-13 compliant eQp system .
The following accessories are EN54-10 and EN54-17 approved for use with the X9800 Flame Detector:
part Number
Description
102740-002
Magnet
007739-001
Magnet and Extension Pole
007290-001
Q9033B Stainless Steel Mounting Arm Assembly is for aluminum and stainless steel detectors
007290-002
Q9033A Aluminum Mounting Arm Assembly is for aluminum detectors only
011385-001
Q9033 Collar Attachment
