Det-Tronics X9800 IR Flame Detector User Manual
Page 18

95-8554
16
11.1
features
• Responds to a fire in the presence of modulated
blackbody radiation (i.e. heaters, ovens, turbines)
without false alarm.
• High speed capability — 30 milliseconds.
• Built-in data logging / event monitoring, up to 1500
events (up to 1000 general, 500 alarms).
• Microprocessor controlled heated optics for
increased resistance to moisture and ice.
• Automatic, manual or magnetic oi testing.
• Easily replaceable oi plate.
• Fire, fault and auxiliary relays standard.
• 0 to 20 mA isolated output (optional).
• Eagle Quantum Premier LON/SLC output (optional).
• HART communication (optional)
• A tri-color LED on the detector faceplate indicates
normal condition and notifies personnel of fire alarm
or fault conditions.
• Operates under adverse weather conditions.
• Mounting arm allows easy sighting.
• Integral wiring compartment for ease of installation.
• Explosion-proof/flame-proof detector housing. Meets
FM, CSA, ATEX and CE certification requirements.
• Class A wiring per NFPA-72.
• Meets NFPA-33 response requirement for under
0.5 second (available when model selected).
• 3 year warranty.
• Advanced signal processing (TDSA).
• RFI and EMC Directive compliant.
Associated Manuals
List of X9800 related manuals:
specifications
operating voLtage—
24 Vdc nominal (18 Vdc minimum, 30 Vdc maximum).
Maximum ripple is 2 volts peak-to-peak.
poWer consUmption—
Without heater: 2.1 watts at 24 Vdc nominal;
3.5 watts at 24 Vdc in alarm.
2.2 watts at 30 Vdc nominal;
4.0 watts at 30 Vdc in alarm.
Heater only: 8 watts maximum.
Total power:
16.5 watts at 30 Vdc with EOL resistor
installed and heater on maximum.
EOL resistor must be ceramic, wirewound type, rated
5 watts minimum, with actual power dissipation not to
exceed 2.5 watts.
For HART model, refer to Addendum number 95-8637.
poWer Up time—
Fault indication clears after 0.5 second; device is ready
to indicate an alarm condition after 30 seconds.
oUtpUt reLays—
Fire Alarm relay, Form C, 5 amperes at 30 Vdc:
The Fire Alarm relay has redundant terminals
and normally open / normally closed contacts,
normally de-energized operation, and latching or
non-latching operation.
Fault Alarm relay, Form A, 5 amperes at 30 Vdc:
The Fault relay has redundant terminals and
normally open contacts, normally energized
operation, and latching or non-latching operation.
Auxiliary relay, Form C, 5 amperes at 30 Vdc:
The auxiliary relay has normally open / normally
closed contacts, nor mally energized or
de-energized operation, and latching or non-
latching operation.
cUrrent oUtpUt (optional)—
0 to 20 milliampere (±0.3 mA) dc current, with a
maximum loop resistance of 500 ohms from 18 to
19.9 Vdc and 600 ohms from 20 to 30 Vdc.
Lon oUtpUt—
Digital communication, transformer isolated (78.5 kbps).
temperatUre range—
Operating: –40°F to +167°F (–40°C to +75°C).
Storage:
–67°F to +185°F (–55°C to +85°C).
Hazardous location ratings from –55°C to +75°C available
on flameproof model.
hUmiDity range—
0 to 95% relative humidity, can withstand 100%
condensing humidity for short periods of time.
TITLE
FORM NuMbER
Pulse
95-8555
EQP
95-8533
SIL 2 (Safety)
95-8672
HART Addendum
95-8637
Q9033 Mounting Arm
and Collar Attachment
95-8686
Inspector Monitor Software for
X-Series Flame Detectors
95-8581
