Tally Dascom 2610
106
Paper Handling
Feeding method: Friction (Single) and Tractor (FF-front / FF-rear / FF-pull)
Path selection: By selection lever located at the right device side
Paper path: Cut sheets: Front in, front or top out
Fanfold paper: Front or rear in, top out
For details enter the Paper Specifications – 9.3 below
Ribbon Type
Ribbon Cartridge, monochrome;
Wide version: 470 x 93 x 39mm max, (WxDxH), fabric: 13mm height
Narrow version: 330 x 93 x 39mm max, (WxDxH), fabric: 13mm height
Ribbon Life
Wide version: 8 million characters (rolling Draft 10 CPI)
Narrow version: 6 million characters (rolling Draft 10 CPI)
Windows Drivers
Windows Server 2000 / 2003 / 2008 / 2012
Windows 7 and Windows 8 (for 32 and 64bit versions)
 covers Windows XP, Windows 2000 and Windows Vista.
Interfaces
Ethernet 10/100MHz
Parallel (Bi-directional IEEE-1284 nibble mode)
USB 2.0 (Full Speed 12 MHz, B type connector)
For details enter the Interface Specifications – 7.3 above
Input Data Buffer Up to 256KB
Operation Panel
LED version: 4 keys and 5 indicator LEDs
LCD version: 6 keys and LCD with 2 lines x 16 characters
Self test
Menu setting print out
Rolling ASCⅡ80 or 136
Hex-Dump
Noise Level Sound pressure level =
≤ 55 dB(A) in LQ
Environmental
Conditions
Temperature Operating: +10 to +35°C.
Storage: - 5 to +45°C
Transport: - 40 to +70°C
Humidity Operating: 16 to 73% RH (No condensation)
Storage: 5 to 95% RH (No condensation)
Transport: 5 to 95% RH (No condensation)
Dimensions
Wide version: 600 mm (W) x 267 mm (D) x 202 mm (H)
Narrow version: 458 mm (W) x 267 mm (D) x 202 mm (H)
Weight
Wide version: 10.62 kg
Narrow version: 8.1 kg
Power Supply
Unit type: Autosensing wide range power supply
Power cord: Detachable
Voltage rating: AC 100 to 240V / 47Hz to 63Hz
Nominal power: 30W
ESD: Comply with IEC801-2;
Contact discharge: 4kV
Air discharge: 8kV
