Quick start guide Installation
5
ENGLISH
Installation
` Before beginning the
installation procedure
In order to use the automatic cut device in an optimum way with your printer, it is
necessary to limit the left-hand printing position of the paper. One or more of the
8 sleeves supplied must be mounted on the left-hand side of the front round tractor
shaft (as viewed from the front side of the printer) depending on the paper path
used (tractor 1, optional tractor 2 or, on the 2T model, the rear tractor). This pre-
vents the left-hand tractor from sliding too far to the left.
If the left-hand tractor is set too far to the left, a paper jam may occur when using
the automatic cut device.
Tractor 1
Mount 5 sleeves on the front tractor shaft and slide it com-
pletely to the left.
STOP
5 Sleeves
