Quick start guide

Technical data and paper specifications

25

ENGLISH

Technical data and paper specifications

` Cut device

Cut width

400 mm (15.75")

Cut height

minimum form length 63.5 mm (2.5")

Cut duration

1000 ms

±

10%

Cutting accuracy

1 to 2 sheet-sets,

±

1 mm

≥ 3 sheet-sets,

±

2 mm

(depending on the stiffness of the cross perforation)

Cut device activation

manually via the control panel, setting via the Setup
Menu, via interface

Service life

appr. 1 000 000 cuts

Weight

appr. 4 kg

Paper type

only fanfold paper can be cut
