Condux Running Line Tensiometer - Manual (Page 19)

19
Troubleshooting Guide
Problem:
Solution:
Digital display is not functioning
• Turn Electronic Control Box pwer
switch ON
• Check all electrical connections
Numbers on digital display start counting
up and do not stop with no load on the
rope.
• Load cell is not properly connected to
the electronic control box. Verify all
connections are made and are tight
Cable puller does not stop when
programmed tension limit is reached.
• TENSION LIMIT CONTROL if OFF.
Turn to the ON position.
• Tension limit is not set to desired load.
Press “PAR” and then use the UP and
DOWN arrows to set the desired
value.
• Puller is not plugged into the
Electronic Control Box.
Cable puller stops before line tension
reaches preset load limit programmed into
the Electronic Control Box.
• Tension limit is not set to desired load.
Press “PAR” and then use the UP and
DOWN arrows to set the desired
value.
Replacement Parts
Replacement/Repair Part
Part Number
User Guide and Safety Manual 08677378
Fuse, 250 Volt-20 AMP 02289664
Switch, On/Off 02289665
Cord Load Cell 08677375
Light, Red Pilot Indicator 02289666
Alarm, Buzzer ECB 02289667
Button, Alarm Reset ECB 02289668
Char Recorder 08677372
