CiDRA SONARtrac Quick Start User Manual
Page 27
50
Read dynamic variable assignments (4.1)
HART 5 & 6
NO
51
Write dynamic variable assignments (4.1)
HART 5 & 6
NO
52
Set transmitter variable zero (4.1)
HART 5 & 6
NO
53
Write transmitter variable units (4.1)
HART 5 & 6
YES
54
Read transmitter variable information (4.1)
HART 5 & 6
NO
55
Write transmitter variable damping value (4.1)
HART 5 & 6
NO
56
Write transmitter variable sensor serial number (4.1)
HART 5 & 6
NO
57
Read unit tag, descriptor, date (5.0)
HART 5 & 6
NO
58
Write unit tag, descriptor, date (5.0)
HART 5 & 6
NO
59
Write number of response preambles (5.0)
HART 5 & 6
YES
60
Read analogue output and percent of range (5.1)
HART 5 & 6
NO
61
Read dynamic variables and PV analogue output (5.1)
HART 5 & 6
NO
62
Read analogue outputs (5.1)
HART 5 & 6
NO
63
Read analogue output information (5.1)
HART 5 & 6
NO
64
Write analogue output additional damping value (5.1)
HART 5 & 6
NO
65
Write analogue output range values (5.1)
HART 5 & 6
NO
66
Enter/exit fixed analogue output mode (5.1)
HART 5 & 6
NO
67
Trim analogue output zero (5.1)
HART 5 & 6
NO
68
Trim analogue output gain (5.1)
HART 5 & 6
NO
69
Write analogue output transfer function (5.1)
HART 5 & 6
NO
70
Read analogue output endpoint values (5.1)
HART 5 & 6
NO
71
Lock device
HART 6
NO
72 Squawk
HART
6
YES
73
Find device
HART 6
YES
74
Read I/O system capabilities
HART 6
NO
75
Poll sub-device
HART 6
NO
76
Read Lock Device State
HART 6
YES
79
Write device variable
HART 6
NO
80
Read device variable trim points
HART 6
NO
81
Read device variable trim guidelines
HART 6
NO
82
Write device variable trim point
HART 6
NO
83
Reset device variable trim
HART 6
NO
105
Read Burst Mode Configuration
HART 6
NO
106
Flush delayed responses
HART 6
NO
107
Write burst mode transmitter variables (for Command #33) (5.1)
HART 5 & 6
NO
108
Write burst mode command number (5.0)
HART 5 & 6
NO
109
Burst mode control (5.0)
HART 5 & 6
NO
110
Read all dynamic variables (5.0)
HART 5 & 6
NO
111
Transfer service control
HART 6
NO
112
Transfer service
HART 6
NO
113
Catch device variable
HART 6
NO
114
Read caught device variable
HART 6
NO
141
Clear Existing Alarm Condition (see Note 1)
HART 5 & 6
YES
Note 1: CiDRA specific command
Copyright © 2007 CiDRA Corporation
Page 4-7
20984-01 Rev 01
