Peak Ovens
8
MF15 – 3.13
5.0 R EPAIRS & R EPLACEMENTS
5.1 Safety Warning – Disconnection from Supply
Always ensure that the oven is disconnected from the supply before repair work is
carried out.
5.2 Safety Warning - Refractory Fibrous Insulation
Insulation made from High Temperature Insulation Wool
Refractory Ceramic Fibre, (better described as Alumino Silicate Wool) (ASW)
This product contains alumino silicate wool products in its thermal insulation. These materials
may be in the form of blanket or felt, formed board or shapes, mineral wool slab or loose fill wool.
Whilst there is no evidence of any long term health hazards, we strongly recommend that safety
precautions are taken whenever the materials are handled.
Exposure to fibrous dust may cause respiratory disease.
When handling the material always use an approved respiratory protection equipment
(RPE-i.e. FFP3), eye protection, gloves and long sleeved clothing.
Avoid breaking up waste material. Dispose of waste in sealed containers.
After handling rinse exposed skin with water before washing gently with soap (not
detergent). Wash work clothing separately.
Before commencing any major repairs we recommend reference to the European Association
representing the High Temperature Insulation Wool industry (www.ecfia.eu)
We can provide further information on request. Alternatively our service division can quote for
any repairs to be carried out at your premises or ours.
5.3 Panel Removal
Disconnect the oven from the electrical supply.
Control panel. Open the door and remove two screws located in recesses on the left side of the
control panel (these screws are covered with plastic caps). Lift the panel, pull forward the bottom
of the panel, and lower the panel to disengage it from the top of the body. Note that the panel
remains connected by wiring. Do not disconnect any wiring without first making a careful note of
all the connections.
Internal Element Cover. Open the door. Side cover (fan models): remove any screws holding the
panel. Bottom cover (non-fan): no screws; the panel clips into place. Remove the cover.
5.4 Temperature Controller Replacement
301. These controllers are fitted to the back of the control panel, which can be removed as given
above.
Before handling the controller: wear an anti-static wrist strap or otherwise avoid any possibility
of damage to the unit by static electricity.
Refer to the instructions supplied with the replacement controller.
2132, 3216, 3508 etc. Ease apart the two lugs at the side; grip the instrument and withdraw it from
its sleeve; push in the replacement.
