Carbolite CFM Series - Manual

MF10 - 3.08
Installation, Operation &
Maintenance Instructions
Combustion Tube Furnaces
CFM models
This manual is for the guidance of operators of the above Carbolite products and
should be read before the furnace is connected to the electricity supply.
Manuals are supplied separately for the furnace controller
(and overtemperature controller when fitted).
Please read the controller manuals before operating the furnace.
C ONTENTS
Section page
1.0 Symbols & Warnings 2
2.0 Installation 3
3.0 Operation 5
4.0 Maintenance 7
5.0 Repairs & Replacements 9
6.0 Fault Analysis 12
7.0 Circuit Diagrams 13
0 Fuses & Power Settings 15
8.0 Specifications 16
