Page 14
Peak Ovens
14
MF15 – 3.13
8.0 F
USES
&
P
OWER
S
ETTINGS
8.1 Fuses
F1-F2: Refer to the circuit diagrams.
F1
Internal supply
fuses
Fitted if supply cable fitted.
Fitted on board to some types of EMC filter.
on-board and up to 16 Amps: 32mm
x 6mm type F
other: GEC Safeclip
F2
Auxiliary circuit
fuses
Fitted on board to some types of EMC filter.
May be omitted up to 25Amp/phase supply
rating.
2 Amps glass type F
On board: 20mm x 5mm
Other: 32mm x 6mm
Customer fuses Required if no supply cable fitted.
Recommended if cable fitted.
See rating label for amperage; see
table below for fuse rating.
Model
phases
Volts
Supply
Fuse
Volts
Supply
Fuse
Control
Fuse
PN30
1-phase
220-240
5A
110-120
7A
2A
PF30
1-phase
220-240
5A
110-120
10A
2A
PIN60
1-phase
220-240
5A
110-120
5A
2A
PN60
1-phase
220-240
5A
110-120
10A
2A
PF60
1-phase
220-240
7A
110-120
12.5A
2A
PN120
1-phase
220-240
7A
110-120
12.5A
2A
PF120
1-phase
220-240
10A
110-120
20A
2A
PN200
1-phase
220-240
10A
110-120
20A
2A
PF200
1-phase
220-240
12.5A
110-120
25A
2A
PF400
1-phase
220-240
30-32A
5A
PF400
2-phase+N
380/220-415/240
15-16A
5A
PF800
1-phase
220-240
40A
5A
PF800
3-phase+N
380/220-415/240
15-16A
5A
208V models may have a higher fuse rating: check the rating label.
Stoving and Curing (and possibly moisture extraction option) models may have a higher fuse
rating: check the rating label.
8.2 Power Settings
All models are designed for a power limit (
OP.Hi
) of 100% with the following exceptions to date:
- any model on 254V: 89%
- PN200 on 110V: 89%; on 120V: 75%
- PF120 on 208V: 89%
- PF200 on 120V: 90%
