Carbolite VMF/ASTM Series - Manual

MF31 – 3.06
Installation, Operation &
Maintenance Instructions
Models SNF and VMF/ASTM
This manual is for the guidance of operators of the above Carbolite products
and should be read before the furnace is connected to the electricity supply.
Manuals are supplied separately for the furnace controller
(and overtemperature controller when fitted).
Please read the controller manuals before operating the furnace.
C ONTENTS
Section page
1.0 Symbols & Warnings 2
2.0 Installation 3
3.0 Operation 4
4.0 Maintenance 5
5.0 Repairs & Replacements 6
6.0 Fault Analysis 8
7.0 Circuit Diagrams 9
8.0 Fuses & Power Settings 10
9.0 Specifications 12
