Carbolite GPC Series - Manual

MF04 – 3.29
Installation, Operation &
Maintenance Instructions
1200°C - 1300°C Chamber Furnaces
GPC models
This manual is for the guidance of operators of the above Carbolite products and should
be read before the furnace is connected to the electricity supply.
Manuals are supplied separately for the furnace controller
(and overtemperature controller when fitted).
Please read the controller manuals before operating the furnace.
C ONTENTS
Section page
1.0 Introduction 2
2.0 Installation 3
3.0 Operation 5
4.0 Maintenance 7
5.0 Repairs & Replacements 8
6.0 Fault Analysis 11
7.0 Circuit Diagrams 12
8.0 Fuses & Power Settings 15
9.0 Specifications 16
