Carbolite GVC Series - Manual

MF48 - 1.18
Installation, Operation &
Maintenance Instructions
1200°C G-range Tube furnaces
Models GHA, GVA, GHC, GVC
This manual is for the guidance of operators of the above Carbolite products
and should be read before the furnace is connected to the electricity supply.
Manuals are supplied separately for the furnace controller
(and overtemperature controller when fitted).
Please read the controller manuals before operating the furnace.
C
ONTENTS
Section page
1.0 Introduction 2
2.0 Installation 3
3.0 Operation 7
4.0 Maintenance 10
5.0 Repairs & Replacements 11
6.0 Fault Analysis 14
7.0 Circuit Diagrams 15
8.0 Fuses & Power Settings 19
9.0 Specifications 21
