3. List of Components.

WARNING: All images and text in this manual is the property of Blitz Co., Ltd. (Japan).
No parts of this manual may be reproduced, stored in retrieval systems, or transmitted in any way
without prior written permission of Blitz Co., Ltd. (Japan).

1. Compressor

2. Chamber

3. Intake Manifold

7. Tension Bracket A

8. Tension Bracket B

11. Level Gauge Stay 1P

12. Tension Bolt

16. Pulley Collar A

15. Pulley w/ Ribs

4 . I n l e t P i p e

5. Compressor Gasket

6. Alternator Bracket 1P

10. Inlet Pipe Stay

9. Compressor Stay

13. Adjuster Bolt

14. Idle Pulley

20. Intake Manifold

Gasket 1P

17. Pulley Collar B 1P

18. Bracket Collar A

22-

18-φ8 h=7mm

19. Bracket Collar B

22-φ10 h=4mm
