Page 29
29
MK-170 Tile Saw PaRTS liST
Item Description
Qty
Part #
A
Accessories, 170
--
--
A1
Blade, 7 Dia x 5/8 Arbor MK-170
1
153441
A2
Flange, Blade
2
135830
A3
Nut, 5/8-18 UNF
1
135848
A4
Owner’s Manual, 170
1
157243
A7
Wrench, Blade Nut, 15/16 Boxed End
1
134684
A8
Wrench, Blade Shaft, 11/16 Open End, 90
1
157244
B
Arm, Motor Support
--
--
B1
Arm, Motor Support
1
157245
B2
Screw, 1/4-20 x 1/2 Flat Head Phillips Cap
3
155812
C
Assembly, Blade Guard, 7”
1
154811-MK
C1
Guard, 7” Blade
1
154811
C2
Elbow, 1/8 MNPT x 1/4 BARB 90° Brass
1
154652
C3
Knob, Davies
1
151681
C4
Washer, 5/16 SAE Flat
2
151754
C5
Wing nut, 5/16-18 Nylock
1
151746
E
Assembly, Fence, 170
1
157406
E1 Fence, Upper
1
157247
E2 Fence, Lower
1
157248
E3
Screw, 10-24 x 3/8 Pan Head Phillips Machine
2
151097
E4 Knob, 1/4-20 x 3/4 Three Prong
1
157583-2
E5 Knob, 10-32 x 1/2 Three Prong
1
157583-1
E6 Clip, Fence
1
157559
F
Motor Mount
--
--
F1
Motor Mount
1
157403
F2
Washer, 5/16 Split Lock
1
151747
F3
Screw, 5/16-18 x 2 1/2 Hex Head Cap, Full Thread
1
151748
F4
Tag, Serial Number, UL Mark
1
157249-02
G
Motor, 120v/4.7a, 170
--
--
G1
Motor, 120v/4.7a, 170
1
157226-G
G2
Label, Caution, GFCI, 1 x 2 1/8
1
155678
G3
Label, Caution, Receptacle, 1 x 2 1/8
1
154822
G4
Label, Motor, 170
1
157251
G5
Label, Warning, Read Owner’s Manual
1
155806
G6
Screw, M5-.8 x 20mm Flat Head Phillips Machine
5
157404
G7
Nut, M5-.8 Hex
5
157405
H
Pan, Water, 170
--
--
H1
Pan, Water, 170
1
157252
J
Splash Curtain
--
--
J1
Curtain, Splash
1
134841
J2
Bracket, Splash Curtain
1
155901
J3
Washer, 1/4 SAE Flat
1
151915
J4
Wing-screw, 1/4-20 x 1/2
1
151888
