12
PRODUCT SPeCiFiCaTiONS
GeNeRal DSCRiPTiON
MOTOR SPeCiFiFCaTiONS
BlaDe CaPaCiTY
Tile TYPeS
The MK-170 is a versatile Tile Saw. Operated and used according to the manual, the MK-170 will
provide years of dependable services.
The MK-170 Tile Saw is engineered as a tabletop or stand mounted wet tile saw. The saw
includes a powerful 120V direct drive AC motor. The saw is capable of cutting tile up to twelve
(12) inches in length and one and three quarter (1-3/4) inches thick in one pass.
Motor specifications for the MK-170 are listed in the table below.
The MK-170 uses a seven (7) inch (178 mm) diameter, wet cutting continuous rim, MK Diamond
blade with a five-eighths (5/8) inch (15.875 mm) arbor.
The MK-170 can cut a variety of tile types including Porcelain, Terracotta, Marble, Quarry and
Slate, or almost any other non-ferrus material.
The MK-170 is not designed to cut plastic or ferrous (metals) material. NOTe:
Voltage 120V
Motor Amperage 5
Frequency 50/60 Hz
RPM 5500 rpm
Watts 560
Weight 15 lbs
MK-170 Tile Saw PRODUCT SPeCiFiCaTiONS
lOCKOUT
The MK-170 is provided with a Lockout device designed to prevent the operation of the saw when
the owner is not around. This Lockout device is a removable Toggle found on the "Rocker" of the
ON/OFF Switch. The Removable Toggle has the words "Remove to Lock" imprinted on the top.
(A)
Remove the Toggle from the
ON/OFF Switch before using.
