Switchplate
Split Lockwasher (2)
#8-32 Nut (2)
Dash
2" or 2 1 /
16
"
Dia. Hole
#8-32 Round
Head Screw (2)
Mounting Switch to Switchplate
rubber Gasket
Switchplate
Lockwasher
Nut
Knob
Mounting Switch to Dash
Memory tachometers record the highest rPM reached during each race.
This memory feature operate as shown below.
Use As Tach
Race with the switch in “TACH” position.
The tach will function as normal to monitor
engine rPM.
Recall RPM
Switch to “RECALL” to display peak RPM.
This can be done during or after a race. To
clear for next race, see Erase Memory step.
Erase Memory
Switch to “ERASE” mode before each race.
This clears previous runs from the memory.
recording will begin when switch is returned to
TACH mode.
REMOTE MEMORY SWITCH
REMOTE MEMORY FEATURE
Memory tachometers record the highest rPM reached during each race.
This memory feature operates as follows.
ErASE MEMorY: Push “ErASE” button before each race. This clears the
memory from the previous runs. You are now ready to record.
rECALL rPM: Push “rECALL” button to display the highest rPM reached.
TACH FACE MEMORY CONTROLS
LIGHT REPLACEMENT
LIGHT REPLACEMENT FOR 5" TACHS LIGHT REPLACEMENT FOR 3¾" TACHS
rotate twist-lock socket counterclockwise and
remove. replace the old bulb with Auto Meter
No. 3218 or GE86 Bulb.
remove rubber plug. rotate twist-lock socket counterclockwise
using needle nose pliers and remove. replace old bulb with Auto
Meter No. 3206 or GE 194 bulb.
rubber Plug
