Rev. A1, 2/14 DCR-1006A Ultrasonic Controller
37
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
• Specifications
Sensor Operating Ranges:
DST or MNU 5000 series: 4 to 72 in. (101 to 1829 mm)
DST or MNU 7000 series: 6 to 144 in. (150 to 3658 mm)
DST or MNU 2000 series: 1 to 25 ft. (305 to 7620 mm)
DST or MNU 3000 series: 1.5 to 40 ft. (458 to 12192 mm)
Operating Voltage: 85-264 VAC or 12-24 VDC
4-20mA Vs: 9 to 28 VDC
Housing: PBT/Polycarbonate blend
Dimensions (in.): 6.25 x 3.125 x 2.25
Environmental Rating: NEMA 6P
Sample Rate: 100 to 1000 mS (programmable)
Resolution: 0.1 in. (2.5 mm)
Accuracy: +/- 0.25% of detected range (with no temperature gradient)
Sensor Adjustments: via push buttons or RS-485 interface to the APG Modbus
Software or RST-5002 module.
Operating Temperature: -30 to 140
0 F (-34 to 60 0 C)
Sensor Beam Pattern: 9 0 off-axis (maximum)
• Inspection and Maintenance
The DCR-1006A requires little maintenance but should be inspection
periodically to ensure proper working order. Keep the sensor clean from heavy
buildup on the sensing face. Ensure that the wire connections are secure,
sealed against the elements and free from corrosion.
