• Programming
The DCR-1006A can be programmed using the on-board push buttons or by
using the RS-485 NET interface to communicate with APG’s Modbus software or
RST-5002 communications module.
Push Button Functions:
ENTER
Opens the programming menu, selects menu options, accepts parameter set-
tings, and steps left one digit within any numeric settings.
NOTE: In order to save changes to a parameter setting, the ENTER button
must be used to exit the setting.
BACK
Steps back (upward) one level within the menu. Steps right one digit within any
numeric parameter setting.
NOTE: Exiting a parameter setting using the BACK button will not save any
changes made to setting.
UP
and
DOWN
Used to cycle through the options within each menu level or to increase or
decrease the value of the flashing digit within a numeric setting.
