DCR-1006A Ultrasonic Controller

25

Automation Products Group, Inc.

APG...Providing tailored solutions for measurement applications

Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]

VERTOV

(Vertical Oval)

Parameters:
FULL d (Full Distance)
EMPTYd (Empty Distance)
LENGTH (Tank Length)
DEPTH (Tank Depth)
WIDTH

(Tank Width)

Full

Distance

Empty

Distance

Depth

Length

Width

HORTOV

(Horizontal Oval)

Parameters:
FULL d (Full Distance)
EMPTYd (Empty Distance)
LENGTH (Tank Length)
DEPTH (Tank Depth)
WIDTH (Tank Width)

Length

Width

Depth

Empty

Distance

Full

Distance
