Setting the Trip Point Outputs:

Step 1: Press once to enter the main setup menu.

Step 2: Press or to cycle through the options until OUTPUT is

displayed.

Step 3: Press to access the Output Settings menu.

Step 4: Press or to cycle through the options until T1TYPE (or

T2TYPE)

is displayed.

Step 5: Press to access the Trip Type setting.

Step 6: Press or to change the setting to the desired trip type function.

Step 7: Press to accept the trip type function and return to the Output

Settings

menu.

Step 8: Press or to cycle through the Output menu options until

T1PRES (or T2PRES) is displayed.

Step 9: Press to enter the Trip Pressure setting. A 5-digit number will

appear with the fi rst digit fl ashing.

Step 10: Press or to change the value of the fi rst fl ashing digit.

Step 11: Press to accept the value of the fl ashing digit and advance to the

next digit......repeat steps 10 and 11 until the desired Trip Pressure is

fully entered.

Step 12: Press or to cycle through the Output menu options until T1WIN

(or T2WIN) is displayed.

Step 13: Press to enter the Trip Window setting. A 5-digit number will

appear with the fi rst digit fl ashing.

Step 14: Press or to change the value of the fi rst fl ashing digit.

Step 15: Press to accept the value of the fl ashing digit and advance to the

next digit......repeat steps 14 and 15 until the desired Trip Window is

fully

entered.

Step 11: To exit the output menu, press or until EXIT is displayed and

press to exit to the main setup menu.

MODE

ENTR
