Setting Event Logging:
When Event Logging is enabled, the gauge will log readings based on the status
of one or both of the Trip Relays (see Trip Relay programming on pages 30-32).
NOTE: Gauges not equipped with relay outputs will still use the Trip Relay
settings for event logging.
Event logging can be set to initiate on one of the following conditions:
When Trip 1 is On (T1ON)
When Trip 2 is On (T2ON)
When both Trip 1 & Trip 2 are On (T1T2ON)
When both Trip 1 & Trip 2 are Off (T1T2OF)
When Trip 1 is Off (T1OFF)
When Trip 2 is Off (T2OFF)
Step 1: Press to enter the main setup menu.
Step 2: Press or to cycle through the options until dATLOG is
displayed.
Step 3: Press to enter the Datalogging menu.
Step 4: Press or to cycle through the options until EVENT is displayed.
Step 5: Press to access the Event options.
Step 6: Press or to cycle through the options until the desired Event
condition is displayed.
Step 7: Press to accept the event condition and return to the Datalogging
menu.
MODE
ENTR
ENTR
ENTR
