Bar Graph 0% (bAR 0) & Bar Graph 100% (bAR100) Settings:
Allows the user to defi ne the reading values associated with 0% and 100% on
the 270

display bar graph. Bars will appear/disappear in 10% increments of the

total span between the two values.

NOTE: The 0% reference does not have to be the lower pressure setting;
0% can be set as the higher pressure setting, thereby causing the bar graph to
increase as the pressure decreases. Negative pressure settings can also be used
as either the 0% or 100% reference points.

Setting the Display Bar Graph:

Step 1: Press once to enter the main setup menu.

Step 2: Press or to cycle through the options until AdVSET is

displayed.

Step 3: Press to access the Advanced Settings menu.

Step 4: Press or to cycle through the options until BAR 0 is displayed.

Step 5: Press to access the Bar Graph 0% value. A 5-digit number will

appear with the fi rst digit fl ashing.

Step 6: Press or to change the value of the fi rst fl ashing digit.

Step 7: Press to accept the value of the fl ashing digit and advance to the

next digit......repeat steps 6 and 7 until the desired 0% reading is fully

entered.

Step 8: Press or to cycle through the options until BAR100 is displayed.

Step 9: Repeat Steps 5-7 to enter the Bar Graph 100% value.

Step 10: To exit the advanced setup menu, press or until EXIT is

displayed and press to exit to the main setup menu.

MODE

ENTR
