Step 8 - fastening frame to existing building – Anchor NAVI-TRAC LITE PAVILLION - 12 TO 24 User Manual
Page 14
Frame Attaching Bracket
U-Shaped stabilizer may not be
used at corner uprights due to
fabric interference.
Connection to existing building
must be determined by cus-
tomer.
Step 8 - Fastening Frame to Existing Building
At back of pavilion, adjust the frame attaching bracket so that is is fi tted up to existing building.
Customer must determine and install the type of device that is best suited to attach frame to existing building.
•
•
14
