Anchor NAVI-TRAC 30 WIDE GABLE-END User Manual
Page 17
HIP/GABLED END COMBINATION UNIT
SEE THE STANDARD NAVI-TRAC
INSTALLATION INSTRUCTIONS FOR
ASSEMBLY OF THE HIP END UNIT.
EXTENSION BEAMS ARE PIVOTED
IN THE SAME MANNER AS SHOWN
PREVIOUSLY IN THIS GABLED END
ASSEMBLY INSTRUCTION.
SEE BELOW FOR COMPONENTS THAT
MUST BE SUBSTITUTED IN HIP END UNIT
(SEE KIT #3)
E15
EIW
CW
BFW
H21-4
MRW
EFW
TFW
MLW
HIP (KIT #3) COMPONENTS
(NOTE: MRW & MLW ARE SUPPLIED
WITH THE “STARTER’ FRAMES)
17
