AirLive WT-2000ARM User’s Manual
44
UPnP
When the UPnP function is enabled, the router can be detected by UPnP compliant system such as
Windows XP. The router will be displayed in the Neighborhood of Windows XP, so you can directly
double click the router or right click the router and select “Invoke” to configure the router through web
browser.
Parameter
Description
UPnP
Activated or deactivated the UPnP function.
Auto-configured
Select this check box to allow UPnP-enabled applications to
automatically configure the router so that they can communicate
through the router, for example by using NAT traversal, UPnP
applications automatically reserve a NAT forwarding port in order to
communicate with another UPnP enabled device; this eliminates the
need to manually configure port forwarding for the UPnP enabled
application.
