AirLive WT-2000ARM User’s Manual
34
Routing
z Routing Table List
You can see the current routing table of the router here. If you want to add another routing rule, please
click “ADD ROUTE”.
Parameter Description
Dest IP Show the IP Address of the destination LAN.
Mask Show the Subnet Mask of the destination LAN. If it shows “8” that
means the Subnet Mask is “255.0.0.0”; “16” means the Subnet Mask
is “255.255.0.0”; “24” means the Subnet Mask is “255.255.255.0”.
Parameter Description
Gateway IP The next stop gateway of the path toward the destination LAN. This
is the IP of the neighbor router that this router should communicate
with on the path to the destination LAN.
Metric The number of hops (routers) to pass through to reach the
destination LAN. It must be between 1 and 15.
Device Show the interface that go to the next hop (router), such as LAN
