AirLive WT-2000ARM User’s Manual
27
segment size (MSS) for transient packets that traverse a router,
specifically TCP segments in the SYN bit set, when PPPoE is being
used in the network. Please specify the MSS range from 100 to 1452
bytes or 0 byte as the default value.
Parameter Description
Get IP Address Choose Static or Dynamic IP Address. If Static IP is selected, please
set the IP Address, Subnet Mask and Gateway obtained from your
ISP.
Static IP Address Enter the IP Address assigned by your ISP.
IP Subnet Mask Enter the Subnet Mask assigned by your ISP.
Gateway Enter the Gateway assigned by your ISP.
NAT NAT (Network Address Translation), an Internet standard that
enables a local-area network (LAN) to use one set of IP addresses
for internal traffic and a second set of addresses for external traffic.
When NAT is enabled, the router will help to make all necessary IP
address translations for the PC connected to the router to access the
Internet.
Default Route When “Default Router” is enabled, all the packets for destinations
not known by the router's routing table are sent to the default route.
By default, it is enabled.
TCP MTU Option MTU (Maximum Transmission Unit) determine the maximum size of
each packet in any transmission within the network. Please specify
the MTU range from 100 to 1500 bytes or 0 byte as the default
value.
Dynamic Route Dynamic routing allows routing tables in routers to change as the
possible routes change. This router supports RIP1, RIP2-B and
RIP2-M protocols for dynamic routing. After the RIP protocol is
selected, please choose the RIP direction from “None”, “Both”, “IN
Only” or “OUT Only”.
Parameter Description
