3. Advanced Functions
WN-350R User’s Manual 116
Here are descriptions of every setup items:
Enable Port Check this box to enable port mapping, and uncheck
Forwarding (1): this box to disable port mapping.
Private IP (2): Input the IP address of the computer on local network
which provides internet service.
Computer Name (3): Pull down the menu and all the computers connected to
the router will be listed here. You can easily to select the
computer name without checking the IP address of the
computer.
Type (4): Select the type of connection, TCP or UDP. If you’re not
sure, please select ‘Both’.
Port Range (5): Input the starting port number in the left field, and input
the ending port number in the right field. If you only want
to redirect a single port number, just fill the port number
in the left field.
Comment (6): Please input any text to describe this mapping, up to 16
alphanumerical characters.
Add (7): Add the mapping to port forwarding table.
Reset (8): Remove all inputted values.
Port Forwarding All existing port forwarding mappings will
Table (9): be displayed here.
